ER.01.032 Eyelet Guide
Flanged, through-bored guides for textile machinery and cable-industry ceramics, steering yarn and wire where they pass through the machine.
Shared image for the catalogue page — not a photo of this part.
Dimension letters are marked on the technical drawing.
Dimensions
- ØD
- 6mm
- D1
- 7,8mm
- Ød
- 3,4mm
- H
- 6,7mm
- h
- 3,7mm
