ER.10.399 Special Guide
Ceramic guides made to a machine-specific shape. Plates, angled bodies and custom bores belong to this group.
Shared image for the catalogue page — not a photo of this part.
Dimension letters are marked on the technical drawing.
Dimensions
- ØD
- 9.8mm
- ØD1
- 3.8mm
- L
- 37.6mm
- Ød
- 0.8mm
- e
- -
- f
- -
Similar products
Hover over a card or tap the dots below it to see that product’s dimensions or technical drawing.
Product group: Special Guides · Product code: ER.10.399 · ØD 9.8 · ØD1 3.8 · L 37.6 · Ød 0.8 · e - · f -
