ER.10.320 Special Guide
Ceramic guides made to a machine-specific shape. Plates, angled bodies and custom bores belong to this group.
Shared image for the catalogue page — not a photo of this part.
Dimension letters are marked on the technical drawing.
Dimensions
- ØD
- 8.5mm
- ØD1
- 9.7mm
- Ød
- 4.3mm
- H
- 4.5mm
- L
- 17mm
Similar products
Hover over a card or tap the dots below it to see that product’s dimensions or technical drawing.
Product group: Special Guides · Product code: ER.10.320 · ØD 8.5 · ØD1 9.7 · Ød 4.3 · H 4.5 · L 17
