ER.10.152 Special Guide
Ceramic guides made to a machine-specific shape. Plates, angled bodies and custom bores belong to this group.
Shared image for the catalogue page — not a photo of this part.
Dimension letters are marked on the technical drawing.
Dimensions
- ØD
- 11.5mm
- ØD1
- 14.3mm
- Ød
- 6.1mm
- H
- 7.8mm
- L
- 24.5mm
Similar products
Hover over a card or tap the dots below it to see that product’s dimensions or technical drawing.
Product group: Special Guides · Product code: ER.10.152 · ØD 11.5 · ØD1 14.3 · Ød 6.1 · H 7.8 · L 24.5
